7 Proven Steps: PQC in CI with ML-KEM Gate & CBOM

Engineering leaders don’t need more theory—you need merge-blocking controls and audit-ready artifacts. This guide shows how to operationalize PQC in CI by shipping two core capabilities:

• A cryptography bill of materials (CBOM) that inventories algorithms, key sizes, and crypto libraries across code, containers, and services.
• A merge gate for ML-KEM readiness (a.k.a. Kyber) that prevents new quantum-vulnerable tech debt, supports hybrid KEM planning, and proves crypto-agility for audits.

You’ll get runnable snippets for GitHub Actions/GitLab CI, OPA/Rego policies, and lightweight scanners you can adapt in a sprint.

---

What you’ll build

• CBOM pipeline: repo + container scanning with JSON output (per service).
• Crypto policy with allowed/disallowed primitives and key floors.
• ML-KEM readiness gate to block merges that add quantum-vulnerable usage without waivers.
• Exception registry with time-boxed waivers + SOC 2/ISO 27001/PCI mapping.
• Evidence pack: signed CI logs, policy commit hash, CBOM snapshot, and exception ledger.

---

Step 1 — Build a CBOM (code, containers, services)

Create a repo-local scanner to enumerate algorithms, key sizes, and libraries. Treat it like an SBOM, but for cryptography.

tools/cbom_scan.py (Python 3.11)

#!/usr/bin/env python3
import os, re, json, glob, hashlib
from pathlib import Path

ALG_PATTERNS = {
  # algorithms (extend as needed)
  "md5": r"\bmd5\b",
  "sha1": r"\bsha1\b",
  "sha256": r"\bsha-?256\b|\bSHA256\b",
  "sha3_256": r"\bsha3[-_]?256\b",
  "des": r"\bdes(_?ede3)?\b|\b3des\b|\btriple[-_]?des\b",
  "rc4": r"\brc4\b",
  "aes_ecb": r"aes[-_]?ecb",
  "aes_gcm": r"aes[-_]?gcm",
  "chacha20_poly1305": r"chacha20[-_]?poly1305",
  "rsa": r"\brsa\b",
  "ecdsa": r"\becdsa\b",
  "x25519": r"\bx25519\b",
  "ml_kem": r"\b(ml[-_]?kem|kyber(512|768|1024))\b"
}
LIB_HINTS = [r"pyca/cryptography", r"OpenSSL", r"wolfSSL", r"BoringSSL", r"libsodium", r"NaCl", r"mbedTLS", r"liboqs"]

# file globs to inspect
GLOBS = ["**/*.py","**/*.js","**/*.ts","**/*.go","**/*.java","**/*.rs","**/*.c","**/*.cpp","**/*.cs","**/*.rb","**/*.php","**/*.scala"]

def scan_file(path):
    text = Path(path).read_text(errors="ignore")
    hits = []
    for name, rgx in ALG_PATTERNS.items():
        m = re.findall(rgx, text, flags=re.I)
        if m:
            hits.append({"algo": name, "count": len(m)})
    libs = []
    for hint in LIB_HINTS:
        if re.search(hint, text, re.I):
            libs.append(hint)
    return hits, list(set(libs))

def key_size_guess(path, text):
    # rough key floor detection; extend for your stack
    ks = []
    for m in re.finditer(r"RSA\W*(\d{3,5})", text, re.I):
        ks.append({"algo": "rsa", "bits": int(m.group(1))})
    for m in re.finditer(r"(P-256|P-384|P-521|ed25519|x25519)", text, re.I):
        ks.append({"algo": "ec", "curve": m.group(1)})
    return ks

def scan_repo(root="."):
    results = []
    for pattern in GLOBS:
        for f in glob.glob(os.path.join(root, pattern), recursive=True):
            try:
                txt = Path(f).read_text(errors="ignore")
            except Exception:
                continue
            algos, libs = scan_file(f)
            ks = key_size_guess(f, txt)
            if algos or libs or ks:
                results.append({"file": f, "algos": algos, "libs": libs, "key_hints": ks})
    return results

if __name__ == "__main__":
    out = {
      "service": os.environ.get("SERVICE_NAME","unknown"),
      "commit": os.environ.get("GIT_COMMIT",""),
      "findings": scan_repo(),
      "container_libs": [],  # to be filled by Step 1b
      "ts": os.popen("date -Iseconds").read().strip()
    }
    print(json.dumps(out, indent=2))

Containers: add a tiny inspector that prints crypto libs present in images.

tools/cbom_container.sh

#!/usr/bin/env bash
set -euo pipefail
IMG="${1:-app:latest}"
tmp=$(mktemp -d)
cid=$(docker create "$IMG" sh -c 'true')
docker export "$cid" | tar -C "$tmp" -xf -
docker rm "$cid" >/dev/null

# naive scan for library names / providers
grep -R -Ei 'lib(ssl|crypto|oqs)|oqsprovider|wolfssl|mbedtls|libsodium' "$tmp" | cut -d: -f1 \
  | sort -u | head -n 200 > cbom_container_libs.txt

jq --argfile libs <(jq -R -s 'split("\n")|map(select(length>0))' cbom_container_libs.txt) \
   '.container_libs = $libs' cbom.json > cbom.out.json || cp cbom.json cbom.out.json

GitHub Actions (extract + publish CBOM)

name: cbom
on: [push, pull_request]
jobs:
  make-cbom:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - name: Python deps
        run: pipx install jq && python -V
      - name: Run CBOM scanner
        env: { SERVICE_NAME: usersvc, GIT_COMMIT: ${{ github.sha }} }
        run: |
          python tools/cbom_scan.py > cbom.json
      - name: (optional) Container CBOM
        run: |
          docker build -t app:ci .
          bash tools/cbom_container.sh app:ci || true
      - name: Upload CBOM
        uses: actions/upload-artifact@v4
        with: { name: cbom-${{ github.sha }}, path: cbom*.json }

---

Free Website Vulnerability Scanner — Landing

---

Step 2 — Define a crypto policy (one file, reviewable)

policy/crypto-policy.yaml

version: 1
allowed_primitives:
  # plan for hybrid today, ML-KEM soon; adapt to org roadmap
  key_establishment: ["ECDH-P256+ML-KEM-768", "X25519+ML-KEM-768", "ML-KEM-768"]
  bulk_cipher: ["AES-GCM-128","AES-GCM-256","CHACHA20-POLY1305"]
  hash: ["SHA-256","SHA-384","SHA3-256","SHA3-384"]
  signature: ["Ed25519","ECDSA-P256","ML-DSA-65"]  # transitional + target
disallowed:
  - "MD5"    # collision-broken
  - "SHA-1"  # collision-broken
  - "DES"    # weak
  - "RC4"    # weak
  - "AES-ECB" # malleable
floors:
  rsa_min_bits: 3072
  ecc_allowed_curves: ["P-256","P-384","X25519"]
classify:
  quantum_vulnerable:
    - "RSA"
    - "ECDH"
    - "ECDSA"
waiver:
  max_days: 180
  needs:
    - owner
    - reason
    - compensating_controls
    - exit_by

Keep this as code in the repo so changes go through PRs like any other policy.

---

Step 3 — Gate disallowed primitives in CI

Use OPA/Rego to read the CBOM and fail merges if policy violations exist without a valid waiver.

policy/cbom.rego

package cbom.gate

default deny := []

# Input shape: { "cbom": {...}, "policy": {...}, "waivers": [...] }

violation[v] {
  f := input.cbom.findings[_]
  a := f.algos[_]
  banned := input.policy.disallowed[_]
  lower(a.algo) == lower(banned)
  v := {"file": f.file, "reason": sprintf("Disallowed primitive: %s", [a.algo])}
}

weak_rsa[v] {
  f := input.cbom.findings[_]
  k := f.key_hints[_]
  k.algo == "rsa"
  k.bits < input.policy.floors.rsa_min_bits
  v := {"file": f.file, "reason": sprintf("RSA key too small: %d", [k.bits])}
}

quantum_vuln[v] {
  f := input.cbom.findings[_]
  a := f.algos[_]
  qv := input.policy.classify.quantum_vulnerable[_]
  lower(a.algo) == lower(qv)
  not has_valid_waiver(f.file)
  v := {"file": f.file, "reason": "Quantum-vulnerable usage without waiver"}
}

has_valid_waiver(file) {
  w := input.waivers[_]
  w.file == file
  now := time.now_ns()
  ttl := input.policy.waiver.max_days * 24 * 3600 * 1e9
  now - time.parse_rfc3339_ns(w.expires) < ttl
}

deny := concat_array([violation, weak_rsa, quantum_vuln])

Waiver ledger (time-boxed, reviewable)

exceptions/waivers.yaml

- file: "svc/payments/legacy_rsa.go"
  owner: "payments-team"
  reason: "Legacy partner requires RSA-2048; migration scheduled."
  compensating_controls: ["TLS 1.3 only", "short-lived certs", "rate-limit"]
  expires: "2026-03-31T23:59:59Z"

CI step (GitHub Actions)

- name: Evaluate CBOM against policy
  run: |
    pipx install yq
    jq -n --slurpfile c cbom.json \
          --argfile p policy/crypto-policy.yaml \
          --argfile w exceptions/waivers.yaml \
      '{cbom:$c[0], policy:$p, waivers:$w}' > input.json
    curl -L -o opa https://openpolicyagent.org/downloads/latest/opa_linux_amd64
    chmod +x opa
    ./opa eval -I -f pretty -i input.json -d policy 'data.cbom.gate.deny' | tee deny.txt
    if grep -q '{' deny.txt; then
      echo "::error::CBOM policy violations found"
      exit 1
    fi

---

Step 4 — Add an ML-KEM readiness gate

The aim is to prove crypto-agility and prevent new debt. Start with configuration and dependency signals, then evolve to runtime validation.

Option A — Dependency/config signals (fastest)
Require any service handling key establishment to declare a PQC plan.

crypto.yml (per service)

service: usersvc
key_establishment_target: "ECDH-P256+ML-KEM-768"   # target hybrid
status:
  runtime_lib: "OpenSSL-3.x"
  pqc_provider: "oqsprovider"        # or "none" if not yet enabled
  rollout: "pilot"                    # pilot | partial | full
milestones:
  enable_provider_in_staging: "2026-01-31"
  hybrid_kem_in_prod: "2026-06-30"

CI check: block merges that introduce new ECDH/RSA usage without an ML-KEM plan.

# tools/mlkem_gate.sh
set -euo pipefail
git diff --name-only origin/main...HEAD | xargs -I{} grep -nE 'ECDH|RSA' {} | tee kem_hits.txt || true
plan=$(yq '.key_establishment_target' crypto.yml)
if [ -s kem_hits.txt ] && ! grep -qi 'ML-KEM' <<< "$plan"; then
  echo "::error::New key-establishment usage without ML-KEM plan in crypto.yml"
  exit 1
fi

Option B — Runtime provider presence (when feasible)
If you ship OpenSSL with OQS provider (or equivalent), assert the provider is loadable in CI images.

# minimal provider probe
openssl list -providers 2>/dev/null | grep -i oqs || {
  echo "::warning::OQS provider not present; ML-KEM readiness = false"
  exit 1
}

Option C — Policy-as-code (OPA)
Fail if CBOM contains quantum-vulnerable key establishment and crypto.yml.status.rollout isn’t at least pilot.

policy/mlkem.rego

package pqc.gate

deny[msg] {
  some f
  f := input.cbom.findings[_]
  some a
  a := f.algos[_]
  lower(a.algo) == "rsa"  # or "ecdsa"/"ecdh"
  input.crypto.status.rollout == "none"
  msg := sprintf("Quantum-vulnerable KE without ML-KEM rollout plan: %s", [f.file])
}

---

Step 5 — Generate a remediation backlog (with exit-by dates)

Turn the CBOM into issues with deadlines aligned to your policy.

# tools/backlog_from_cbom.py
import json, datetime, sys
cbom = json.load(open("cbom.json"))
out = []
deadline = (datetime.date.today() + datetime.timedelta(days=180)).isoformat()
for f in cbom["findings"]:
    for a in f["algos"]:
        if a["algo"].lower() in ["md5","sha1","des","rc4","aes_ecb"]:
            out.append({"title": f"Replace {a['algo']} in {f['file']}",
                        "labels": ["crypto-remediation","high"],
                        "exit_by": deadline})
    for k in f.get("key_hints", []):
        if k.get("algo") == "rsa" and k.get("bits", 0) < 3072:
            out.append({"title": f"Rotate RSA key (<3072) in {f['file']}", "labels":["crypto-remediation","med"], "exit_by": deadline})
print(json.dumps(out, indent=2))

Pipe this into your ticket API (GitHub, Jira) to auto-create work with clear “exit by” dates.

---

Step 6 — Produce audit-ready evidence (signed)

Capture and sign policy + CBOM + logs so audits don’t become archaeology.

# scripts/evidence.sh
set -euo pipefail
mkdir -p evidence
cp policy/crypto-policy.yaml evidence/
cp cbom.json evidence/
git rev-parse HEAD > evidence/policy_commit.txt
tar -czf evidence.tar.gz evidence
# sign with cosign keyless or GPG (choose one)
cosign sign-blob --yes evidence.tar.gz > evidence.sig || gpg --armor --detach-sign evidence.tar.gz

Upload evidence.tar.gz + signature as build artifacts and reference them in your change record.

Control mapping (examples)

• SOC 2 CC6/CC7: preventive merge gates + detective logs.
• ISO 27001 A.8 / A.14: crypto policy and secure development controls.
• PCI DSS 6 & 10: secure coding checks + logging evidence.

---

Step 7 — Rollout pattern that works

1. Pilot on one critical service (warn-only → block).
2. Policy package org-wide (policy + OPA bundles + exception workflow).
3. Vendor validation (add to your questionnaire):
   • Do your services support ML-KEM (or hybrid) for TLS/KE?
   • Provide your crypto policy and exception ledger with expiry dates.
   • Share a CBOM snapshot and a plan to exit quantum-vulnerable usage.

---

Sample report — Findings excerpt to check Website Vulnerability

When you’re ready for a deeper review or assessor-ready packaging, explore:

• Risk Assessment Services — map CI outputs to SOC 2/ISO/PCI and plan the rollout.
• Remediation Services — close gaps quickly with engineer-friendly fixes.

Risk Assessment Services | Remediation Services | Free Website Security Scanner

---

GitLab CI equivalents (quick start)

stages: [cbom, policy]

cbom:
  stage: cbom
  image: python:3.11
  script:
    - pip install jq yq || true
    - python tools/cbom_scan.py > cbom.json
  artifacts:
    when: always
    paths: [cbom.json]

policy:
  stage: policy
  image: alpine:3.20
  script:
    - wget -qO opa https://openpolicyagent.org/downloads/latest/opa_linux_amd64 && chmod +x opa
    - apk add --no-cache jq yq
    - jq -n --slurpfile c cbom.json \
          --argfile p policy/crypto-policy.yaml \
          --argfile w exceptions/waivers.yaml \
          '{cbom:$c[0], policy:$p, waivers:$w}' > input.json
    - ./opa eval -I -f pretty -i input.json -d policy 'data.cbom.gate.deny' | tee deny.txt
    - test ! -s deny.txt

---

Related reads on our blog

• 5 Proven CI Gates for API Security: OPA Rules You Can Ship — practical OPA policies + evidence workflow.
• 7 Proven Software Supply Chain Security Tactics — SBOM → VEX → SLSA with copy-paste CI.
• 7 Proven Steps for SSDF 1.1 CI/CD Attestation — wire attestations into builds.
• OWASP GenAI Top 10: 10 Proven Dev Fixes — CI gates for LLM features.

---

Final note

If you want help wiring PQC in CI with merge-blocking ML-KEM gates, an actionable CBOM, and audit-ready evidence, our team can pair with your engineers, pilot on one service, and expand org-wide without slowing velocity.

Start with a quick perimeter check: Website Vulnerability Scanner Online Free
Need assessor-ready packaging? Risk Assessment Services • Remediation Services

---
